Main technology parameters
1.Power source:AC380VThree-phase five-wire system
2.Temperature evenness:正副1.5℃
3.The temperature control precision:±1℃
4.Temperature range:30 to 180℃
5.Exhaust velocity:7OL/S
6.Working vacuum degree:200-20Pa
7.Laminating cavity height:20mm
8.Working power:18Kw
9.Air pressure needed:0.5-0.8Mpa
10.Pumping time:5 to 6min
11.Operating environment: Ambient temperature 0 to 50℃
12.Ambient humidity<90%
Function
1.Flexible operate mode, the operation of manual, auto can
be adjusted according to requirement
2.Controlled by PLC,multi-networkde & centralizde contrlo
3.oil-heating method to get a more uniform temperature
4.Various warning & emergency response system to keep
reliable operation
5.High vacuum to ensure produvt quality
6.Special sturctural design & flat plate to avoid displacement
and debris
