Main technology parameters
1.Power source:AC380V Three-phase five-wire system
2.Temperature evenness:t1.5℃
3.The temperature control precision:±1℃
4.Temperature range:30 to 180℃
5.Exhaust velocity:7OL/S
6.Working vacuum degree:200-20Pa
7.Laminating cavity height:20mm
8.Working power:18Kw
9.Air pressure needed:0.5-0.8Mpa
10.Pumping time:5 to 6min
11.Operating environment: Ambient temperature 0 to 50℃
12.Ambienthumidity<90%
13.Elevation:below 2000m
Function
1.Stable gearing of in & out material to keep more efficient working
2.Controlled by PLC,touch-screen display
3.Using thick heating plates and iol-heating method,the temperature
is more unigorm
4.Hydraulic VOTL method to open the cover, saving the mechanical
operation time
5.Emergency system and safety grating & various accurate warning
systems to ensure a more safe and reliable operation
6.High vacuum to ensure module quality and reduce costs
7.Special structural design & flat plate to avoid displacement and
debris
8.From the perspective of humanization in operations, set the voice
prampts in particular
